Product Name：YP20G
YP series water pump ● Large flow, high head, low noise, low oil consumption, excellent pumping performance ● High-performance four-stroke OHV gasoline engine with oil alarm device ● Convenient operation and comfortable, economic and durable, can also operate efficiently in harsh operating environment.
Details
|
Specification sheet 规格表 |
|
|
Modle 型号 |
YP20G |
|
PUMP 泵体： |
|
|
Pump type 泵体结构 |
Single stage, single suction, coaxial direct connec-tion, high speed centrifugal self suction type 单级、单吸、共轴直联、高速离心自吸式 |
|
Inlet/outlet port diameter (mm) 进/出水口直径 |
50 |
|
Max. capacity (l/min) ****流量 |
600 |
|
Tax.head(m) 最高扬程 |
30 |
|
Max.suction head(m) ****自吸高度 |
7 |
|
Limited self-suction time(s) 规定自吸时间 |
120 |
|
Impeller 叶轮 |
Semi-open structure 半开式 |
|
Connection port 连接口 |
Outer pipe thread 外管螺纹 |
|
GASOLINE ENGINE 汽油机： |
|
|
Modle 型号 |
GT175 |
|
Displacement 排量（cm³） |
171 |
|
Rated output 额定输出 |
3.3kW/3600rpm |
|
Fuel tank availability capacity(l) 燃油箱有效容积 |
4.5 |
|
Fuel standard--Fuel consumption 燃油规格--燃油消耗 |
Vehicle unleaded gasoline--1.7l/Hr 车用无铅汽油 |
|
Starting system 起动方式 |
Recoil starter 手拉反冲起动 |
|
Protection system 保护系统 |
Low oil level protection 低油位保护 |
|
Noise level 噪声 |
≤71dB(A) |
|
Pumassembly configuration 泵组结构 |
Portable frame structure 轻便框架结构 |
|
Net.Weight (Kg) 净重 |
28 |
|
Dimension (LxWxH mm) 尺寸 |
515*395*450 |
|
535*415*470 |
|
|
Sand strainer 沙石过滤器 |
● |
|
Throat collar 喉箍 |
● |
|
Rubber foot mount 橡胶脚垫 |
● |
|
Hose joint 管接头 |
● |
|
O-ring or Gasket O型圈或密封垫 |
● |
|
Spark plug sleeve 火花塞套筒 |
● |
|
OWNER'S MANUAL 用户手册 |
● |
|
Performanc,Quality and standard 性能、品质与标准 |
|
|
|
Techno-standard of the gasoline engine water-pump is according to GB/T 24673-2009, JB/T 6664－2017. The machinery safety is according to GB 10395.8-2006. 汽油机水泵技术标准执行 GB/T 24673-2009, JB/T 6664－2017. 机械安全按照 GB 10395.8-2006. |
